LMX-2804G-4XS-T
28-Port Industrial Managed Gigabit Ethernet Switch- 24*10/100/1000T Gigabit Ethernet + 4*1G/2.5G/10G SFP+ Slots; EOT: -40~75C

Overview of the Antaira LMX-2804G-4XS 28-Port Industrial Managed Switch, Gigabit

LMX-2804G-4XS-T | 28-Port Rackmount | Antaira

$5,378.00 10

Request Information
Online Request for Product Information Form

To request more information regarding our products, please fill out the following online form and a customer service representative will contact you immediately. Fields marked (*) are required. Thank you.

Request Volume Pricing
Online Request for Volume Pricing Form

To request volume pricing of any of our products, please fill out the following online form and a customer service representative will contact you immediately. Fields marked (*) are required. Thank you.

Overview

Antaira Technologies’ LMX-2804G-4XS-T is a 28-port industrial gigabit managed Ethernet switch features 24*10/100/1000Tx Ethernet ports and 4*1G/2.5G/10G SFP+ Slots. This makes the product ideal for applications that demand high density of port connectivity, wide bandwidth and long-distance communication. LMX-2804G-4XS-T is a fully manageable Light Layer 3 Ethernet switch that is pre-loaded with a user-friendly web management console design. It supports the ring network redundancy function using the market’s open standard ITU-T G.8032 ERPS (Ethernet Ring Protection Switch) protocol that has a <50ms network recovery time. The advanced network filtering and security functions, such as IGMP, VLAN, QoS, SNMP, port lock, RMON, Modbus TCP, and 802.1X/HTTPS/SSH/SSL increase determinism and improve network management for remote SCADA systems or control networks. The LMX-2804G-4XS-T is designed with IP30 rated 1U 19” rackmount. Supporting the standard operating temperature model -40° to 75˚C also makes it the best solution for any harsh and extreme ambient weather environment applications, such as power/utility, transportation, water wastewater treatment plant, oil/gas, and security surveillance system industries.

Features

  • Support 24*10/100/1000BASE-T Gigabit Ethernet Ports
  • Support 4*1G/2.5G/10G SFP+ Slots
  • ITU-T G.8032 Ethernet Ring Protection Switch (ERPS) Protocol
  • IEEE 802.1D STP (Spanning Tree Protocol), IEEE 802.1w RSTP (Rapid Spanning Tree Protocol), IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
  • Static Routes, ARP
  • SNMPv1/v2c/v3, RMON, Modbus TCP, and HTTP/HTTPS
  • RADIUS, TACACS+, 802.1X Authentication
  • ACL, IP Source Guard
  • VLAN, QoS, and, SNMPv3
  • IP30 Rugged Metal Case Design
  • Redundant Power Input
  • Fanless Operation
  • Power Reverse Polarity Protection
  • High EFT and ESD Protection
  • Operating Temperature: -40°C to 75°C
  • 5-Year Warranty

Download

Included

Benefits

Accessories


Antaira's industrial rackmount network switches easily increase the functionality of any network. A Gigabit rackmount unmanaged Ethernet switch is ideal for applications that demand high-density Ethernet connectivity, wide bandwidth and long-distance communication within any harsh and extreme ambient weather environment applications. Antaira’s industrial rackmount network switches deliver a high degree of modular flexibility with 26, 28, or 32 port routing and switching capabilities. They also provide fast millisecond-level multicast traffic redundancy for critical infrastructures in city, transportation, manufacturing, surveillance, and other industrial-scale applications. Whether you need an unmanaged plug-and-play model or a managed option for complete configuration options, Antaira has the right device for you.

UTS-USBC-RJ45-A


$59.00

USB-C to 1-Port RS-232 Converter (RJ45) Console Cable
***Designed to work with Antaira switches' console port***
