8-Port Industrial PoE+/4PPoE Unmanaged Ethernet Switch, with 4*10/100Tx (30W/Port) and 4*10/100Tx (60W/Port), 12~36VDC Power Input and extended working temperature range.
To request more information regarding our products, please fill out the following online form and a customer service
representative will contact you immediately. Fields marked (*) are required. Thank you.
To request volume pricing of any of our products, please fill out the following online form and a customer service representative will contact you immediately. Fields marked (*) are required. Thank you.
Overview
Antaira Technologies' LNP-0800-60-24-T is an industrial 4PPoE unmanaged Ethernet switch featuring 4*10/100Tx 4PPoE Type 3 ports and 4*10/100Tx PoE+. Port 1-4 support an IEEE 802.3bt Type 3 high power 4PPoE output up to 60W per port and port 5-8 support an IEEE 802.3at PoE+ output up to 30W per port.
The LNP-0800-60-24-T is IP30 rated and DIN-rail mountable. This switch supports extended temperature range -40°C to 75°C and provides Ethernet connectivity with 4PPoE / PoE+ functions ideal for outdoor or harsh industrial application environments, such as security surveillance, ITS-traffic monitoring systems, facility management for power/utility, water wastewater treatment plants, and automated production lines in factory automation.
Features
4-Port IEEE 802.3at compliant PoE+ Function (30W/Port)
4-Port IEEE 802.3bt compliant 4PPoEP (60W/Port)
Supports Auto MDI/MDI-X Function
Store-and-Forward Switching Architecture
2K MAC Address Table
Network Broadcast Storm Protection
Surge Protection: 2,000 VDC support
ESD Protection: 6,000 VDC support
Redundant Power Input Design – 12~36VDC
Built-in 1 relay output for Port Break Alarm
IP30 Rugged Aluminum Case Design
DIN-Rail and Wall Mount support
Operating Temperature range - EOT: -40° to 75°C
5-Year Warranty
Download
Included
Accessories
Antaira offers top-quality industrial 60-Watt PoE++ injectors and Ethernet switches that reliably deliver powering capabilities for your Ethernet cables. The high-power injector is IEEE 802.3bt Type 3 and is capable of providing up to 60 Watts of power to end devices. The 60W PoE switch supports an IEEE 802.3bt Type 3 high power output up to 60 Watts per port. This device has a redundant power input design of 12 to 36VDC. These units are IP30 rated, DIN-rail mountable and support an extended temperature (-40C to 75C) in rugged application environments.
If you have any questions about our 60-Watt PoE++ injectors and Ethernet switches, please contact us.
